NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2025

ROTOR DISC » RN2025

Specification

Type

Solid

Outter Ø

233

Num. of holes

4

Disc Thickness (Max)

18

Height

29.5

Centering Diameter

91

Pitch Circle Ø

108

Drum Ø:

126

Disc Thickness (Min)

17

Structure Material

G3000

Cross Reference

TOYOTA

43512-BZ020

TOYOTA

43512-BZ050

TOYOTA

43512-BZ180

TOYOTA

43512-BZ190

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Avanza

10.06~11.11	1300	3SZ-VE	F602LM	RN2025	PN1832	DN1109	FN2367
12.03~08.06	1300	K3-DE	F601RM	RN2025	PN1832		FN2367
01.03~11.11	1300	K3-VE	F601RM	RN2025	PN1832	DN1109	FN2367
01.03~11.11	1300	K3VE	F601LM	RN2025	PN1832		FN2367
01.03~11.11	1500	3SZ-VE	F602RM	RN2025	PN1832		FN2367
11.11~08.15	1500	3SZ-VE	F652LM	RN2025	PN1832	DN1109	FN2367
11.11~08.15	1500	3SZ-VE	F652RM	RN2025	PN1832		FN2367
11.11~08.15	1500	K3VE	F651LM	RN2025	PN1832	DN1109	FN2367
