DRUM BRAKE » DN1109

Specification

Outter Ø

239.7

Num. of holes

4

Centering Diameter

60

Pitch Circle Ø

114.3

Structure Material

G3000

Hole Ø

13.1

Height

59.6

Drum Ø

203

Cross Reference

SUZUKI

4309177J00000

TOYOTA

42431-BZ010

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Avanza

08.15~01.23	1300	1NR-VE	F653LM	RN2184V	PN1832	DN1109	FN2367
07.15~01.23	1300	1NR-VE	F653RM	RN2184V	PN1832	DN1109	FN2367
10.06~11.11	1300	3SZ-VE	F602LM	RN2025	PN1832	DN1109	FN2367
01.03~11.11	1300	K3-VE	F601RM	RN2025	PN1832	DN1109	FN2367
08.15~01.23	1500	2NR-VE	F654LM	RN2184V	PN1832	DN1109	FN2367
07.15~01.22	1500	2NR-VE	F654RM	RN2184V	PN1832	DN1109	FN2367
11.11~08.15	1500	3SZ-VE	F652LM	RN2025	PN1832	DN1109	FN2367
11.11~08.15	1500	K3VE	F651LM	RN2025	PN1832	DN1109	FN2367
