MOTORCYCLE BRAKE PADS » PM106

PM106

Specification

Length-1
117
Width-1
48
Thick-1
8.5
Length-2
96.6
Width-2
58
Thick-2
10.8
TYP
R

Cross Reference

years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SUZUKI   »   DR-600

01.89~ 600 PM106 PM538

SUZUKI   »   DR-650

01.90~01.95 650 PM106 PM538
01.92~ 650 PM106 PM538

SUZUKI   »   DR-750

01.88~ 750 PM106
01.89~01.90 750 PM106 PM538

SUZUKI   »   DR-800

01.90~01.90 800 PM106 PM538

SUZUKI   »   DR-Z-800

01.88~01.90 800 PM106 PM210
Copyright © 2003-2024 JNBK Corporation. All Rights Reserved

Exemption from liability: the catalog data is advisory and can be used for reference only
