ROTOR DISC » RN1996
Specification
Type
Solid
Outter Ø
302
Num. of holes
5
Disc Thickness (Max)
10
Height
54.2
Centering Diameter
76
Pitch Circle Ø
114.3
Drum Ø:
190
Disc Thickness (Min)
8.5
Structure Material
G3000
Cross Reference
HYUNDAI
58411-D3000
HYUNDAI
58411-D7000
KIA
58411-D7000
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.20~ | 2000 | D4HD | PTLI20 | RN1653V | PN0661 | RN1996RN2001 | PN0538PN0591 | FN0697 |
| 09.20~ | 2000 | G4NJ | PTLI20 | RN1653V | PN0661 | RN1996RN2001 | PN0591PN0538 | FN0697 |
| 04.15~08.18 | 1600 | G4FJ | PD315 RHD | RN1653V | PN0661 | RN1996RN2001 | PN0591PN0538 | FN0697 |
| 04.15~08.18 | 1700 | D4FD | PD315 | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 03.15~11.18 | 2000 | D4HA | PD315 LHD KDOM | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 04.15~08.18 | 2000 | D4HA | PD315 RHD | RN1653V | PN0661 | RN1996RN2001 | PN0591PN0538 | FN0697 |
| 12.14~08.18 | 2000 | G4NA | PD315 LHD | RN1653V | PN0661 | RN1996RN2001 | PN0591PN0538 | FN0697 |
| 04.15~08.18 | 2000 | G4NA | PD315 RHD | RN1653V | PN0661 | RN1996RN2001 | PN0538PN0591 | FN0757FN0697 |
| 04.15~08.18 | 2000 | G4NC | PD315 | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 04.15~08.18 | 2000 | G4NC | PD315 LHD | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 04.15~08.18 | 1600 | G4FD | PD716 | RN1653V | PN0578 | RN1996 | PN0436 | FN0757 |
| 04.15~08.18 | 1700 | D4FD | PD716 EU LHD | RN1653V | PN0578 | RN1996 | PN0436 | FN0757 |
| 04.15~08.18 | 2000 | D4HA | PD716 | RN1653V | PN0578 | RN1996 | PN0436 | FN0757 |
| 04.15~08.18 | 2000 | G4NA | PD716 GEN | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 04.15~08.18 | 2000 | G4NA | PD716 RUS | RN1653V | PN0578 | RN1996RN2001 | PN0538PN0436 | FN0757 |
| 01.18~03.21 | 1600 | D4FE | PD318 LHD KDOM | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 01.18~09.20 | 1600 | D4FE | PD718 EU | RN1653V | PN0578 | RN2001RN1996 | PN0538PN0436 | FN0757 |
| 01.18~09.20 | 1600 | G4FD | PD718 GEN | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 01.18~09.20 | 1600 | G4FJ | PD318 RHD | RN1653V | PN0661 | RN1996RN2001 | PN0538PN0591 | FN0697 |
| 01.18~09.20 | 1600 | G4FU | NX4 | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 01.18~09.20 | 2000 | D4HA | PD718 GEN | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 01.18~09.20 | 2000 | G4NA | PD318 | RN1653V | PN0661 | RN1996 | PN0538PN0591 | FN0697 |
| 01.18~09.20 | 2000 | G4NA | PD718 GEN | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 01.18~09.20 | 2000 | G4NA | PD718 RUS | RN1653V | PN0578 | RN1996 | PN0436 | FN0757 |
| 01.18~09.20 | 2400 | G4KJ | PD718 GEN | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 07.18~07.21 | 1600 | D4FE | PD919 | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 01.19~07.21 | 1600 | D4FE | PF119 LHD | RN1653VRN1644V | PN0578 | RN1996RN2001 | PN0538PN0436 | FN0757 |
| 01.19~07.21 | 1600 | G4FD | P#814 RHD | RN1653V | PN0661 | RN1996 | PN0591 | FN0697FN0757 |
| 10.15~01.19 | 1600 | G4FD | PF116 LHD | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 10.15~01.19 | 1600 | G4FD | PF116 RHD | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 01.19~07.21 | 1600 | G4FD | PF119 LHD | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 10.15~01.19 | 1600 | G4FJ | PF116 RHD | RN1653V | PN0661 | RN1996 | PN0591PN0538 | FN0697 |
| 05.18~07.21 | 1600 | G4FJ | PF119 RHD | RN1653V | PN0661 | RN1996RN2001 | PN0591PN0538 | FN0697 |
| 10.15~01.19 | 1700 | D4FD | PD916 LHD | RN1653V | PN0578PN0661 | RN1996 | PN0436PN0591 | FN0757FN0697 |
| 10.15~01.19 | 2000 | D4HA | PD916 LHD | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 10.15~01.19 | 2000 | D4HA | PD916 RHD | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 05.18~08.21 | 2000 | D4HA | PD919 LHD | RN1653V | PN0661 | RN1996 | PN0436PN0591 | FN0697 |
| 10.15~01.19 | 2000 | D4HA | PF116 LHD | RN1653V | PN0661PN0578 | RN1996 | PN0436PN0591 | FN0757FN0697 |
| 10.15~01.19 | 2000 | D4HA | PF116 RHD | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 10.15~01.19 | 2000 | G4NA | PD916 LHD | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 10.15~01.19 | 2000 | G4NA | PD916 RHD | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 05.18~08.21 | 2000 | G4NA | PD919 LHD | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 05.18~08.21 | 2000 | G4NA | PD919 RHD | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 10.15~01.19 | 2000 | G4NA | PF116 RU | RN1653V | PN0578 | RN1996 | PN0436 | FN0757 |
| 10.15~11.18 | 2400 | G4KJ | PD916 US | RN1653V | PN0661 | RN1996 | PN0591 | FN0697 |
| 11.18~ | 2400 | G4KJ | PF119 RUS | RN1653V | PN0578 | RN1996 | PN0436 | FN0757 |
