BRAKE SHOE » FN2367T

Specification

Radius
101.6
Width
35
Thickness
7.2
Pcs In Set
4
Notes
Thickness 7.2 mm South America

Cross Reference

BENDIX AUS
BS5027
FMSI
S997-1668
KASHIYAMA
K2367
TOYOTA
04495-BZ010
TOYOTA
04495-BZ011
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
06.07~ 1300 K3-VE3 M80 PN1832 FN2367
06.07~ 1500 3SZ-VE M80 PN1832 FN2367
08.15~01.23 1300 1NR-VE F653LM RN2184V PN1832 DN1109 FN2367
07.15~01.23 1300 1NR-VE F653RM RN2184V PN1832 DN1109 FN2367
10.06~11.11 1300 3SZ-VE F602LM RN2025 PN1832 DN1109 FN2367
12.03~08.06 1300 K3-DE F601RM RN2025 PN1832 FN2367
01.03~11.11 1300 K3-VE F601RM RN2025 PN1832 DN1109 FN2367
01.03~11.11 1300 K3VE F601LM RN2025 PN1832 FN2367
08.15~01.23 1500 2NR-VE F654LM RN2184V PN1832 DN1109 FN2367
07.15~01.22 1500 2NR-VE F654RM RN2184V PN1832 DN1109 FN2367
01.03~11.11 1500 3SZ-VE F602RM RN2025 PN1832 FN2367
11.11~08.15 1500 3SZ-VE F652LM RN2025 PN1832 DN1109 FN2367
11.11~08.15 1500 3SZ-VE F652RM RN2025 PN1832 FN2367
11.11~08.15 1500 K3VE F651LM RN2025 PN1832 DN1109 FN2367

Exemption from liability: the catalog data is advisory and can be used for reference only
