DRUM BRAKE » DN1123

DN1123

Specification

Outter Ø
275.6
Num. of holes
5
Hole Ø
13.1
Centering Diameter
60
Height
60.3
Pitch Circle Ø
114.3
Drum Ø
228.8
Structure Material
G3000

Cross Reference

DAIHATSU
42431-BZ100
TOYOTA
42431-BZ100
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

DAIHATSU   »   Gran Max

10.07~ 1300 K3-DE S401 RN2452V PN1847 DN1123 FN2398
07.20~ 1500 2NR-VE S403 RN2644V PN1847 DN1123 FN2398
11.07~ 1500 3SZ-VE S402 TR RN2452V PN1847 DN1123 FN2398
11.07~ 1500 3SZ-VE S402LVB FOURGON RN2452V PN1847 DN1123 FN2398

DAIHATSU   »   Luxio

01.09~ 1500 3SZ-VE S402RG RN2452V PN1847 DN1123 FN2398

TOYOTA   »   Lite/Townace

07.20~ 1500 2NRVE S403M RN2644V PN1847 DN1123 FN2398
01.08~ 1500 3SZ-VE S402M RN2452V PN1847 DN1123 FN2398

TOYOTA   »   Liteace

06.10~ 1500 3SZ-VE S412M RN2452V PN1847 DN1123 FN2398

TOYOTA   »   Liteace Truck

01.08~ 1500 3SZ-VE S402U RN2452V PN1847 DN1123 FN2398

TOYOTA   »   Liteace Van

01.08~ 1500 3SZ-VE S402M RN2452V PN1847 DN1123 FN2398

TOYOTA   »   Townace Truck

01.08~ 1500 3SZ-VE S402U RN2452V PN1847 DN1123 FN2398
01.21~ 1500 3SZ-VE S403U RN2644V PN1847 DN1123 FN2398
07.10~ 1500 3SZ-VE S412U RN2452V PN1847 DN1123 FN2398
