NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2529V

ROTOR DISC » RN2529V

Specification

Type

Vented

Outter Ø

255

Num. of holes

4

Disc Thickness (Max)

22

Disc Thickness (Min)

19

Height

46.2

Centering Diameter

55

Pitch Circle Ø

100

Front/Rear

Front

Structure Material

G3000

Cross Reference

TOYOTA

43512-K0010

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Aqua

07.21~	1500	M15A-FXE	MXPK10	RN2529V	PN1876	DN1220	FN2417
07.21~	1500	M15A-FXE	MXPK11	RN2529V	PN1876	DN1220	FN2417

TOYOTA » Yaris

01.20~	1000	1KR-FE	KSP210	RN2529V	PN1876	DN1220	FN2417
01.20~	1000	1KR-FE	KSP211	RN2529V	PN1876	DN1220	FN2417
02.20~	1500	M15A-FKS	MXPA10	RN2529V	PN1876	DN1220	FN2417
04.20~	1500	M15A-FKS	MXPA15	RN2529V	PN1876	DN1220	FN2417
02.20~	1500	M15A-FXE	MXPH10	RN2529V	PN1876	DN1220	FN2417
02.20~	1500	M15A-FXE	MXPH14	RN2529V	PN1876	DN1271	FN2389
02.20~	1500	M15A-FXE	MXPH15	RN2529V	PN1866	DN1271	FN2389
02.20~	1500	M15A-FXE	MXPH17	RN2529V	PN1866	DN1271	FN2389
