NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1946V

ROTOR DISC » RN1946V

Specification

Type

Vented

Outter Ø

296

Num. of holes

5

Disc Thickness (Max)

28

Centering Diameter

55

Pitch Circle Ø

100

Front/Rear

Front

Height

49,3

Disc Thickness (Min)

26

Drum Ø:

155

Structure Material

G3000

Cross Reference

TOYOTA

43512-21030

TOYOTA

43512-21031

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Caldina

09.02~06.07

2000

3S-GTE

ST246W

RN1946V

PN1480

RN1254

PN1458
