ROTOR DISC » RN1934V

Specification

Type
Vented
Outter Ø
249.2
Num. of holes
5
Disc Thickness (Max)
18
Height
44
Centering Diameter
64
Pitch Circle Ø
114.3
Disc Thickness (Min)
16
Drum Ø:
139
Structure Material
G3000
Front/Rear
Front
Hole Ø:
12.7
Notes
w/o A.B.S.

Cross Reference

SUZUKI
55311-61J01
SUZUKI
55311-61J01-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.06~ 1600 G16A GC416G LHD PR RN1934V PN1847PN1832 FN9980FN9803
01.13~01.19 1600 G16A GC416V-2 RN1934V PN1847PN1832 DN1414 FN9980
01.04~01.08 1600 G16AID GC416V RN1934V PN1847PN1832 DN1414 FN9803FN9980
01.13~01.19 1600 G16AID GC416V LHD RN1934V PN1847PN1832 FN9803FN9980
01.08~ 1600 G16AID GC416V RHD RN1934V PN1847PN1832 DN1414 FN9803FN9980
01.05~12.12 1600 G16A DN71 RN1934V PN1847PN1832 FN9980
01.06~12.09 1500 G15A GC415# RN1934V PN1832PN1847 FN9980

Exemption from liability: the catalog data is advisory and can be used for reference only
