DRUM BRAKE » DN1414

DN1414

Specification

Outter Ø
262
Num. of holes
5
Hole Ø
12.7
Centering Diameter
64
Height
64.5
Pitch Circle Ø
114.3
Drum Ø
220
Structure Material
G3000

Cross Reference

SUZUKI
43511-61J00
SUZUKI
43511-61J00-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SUZUKI   »   APV

11.07~ 1500 G15A# GC415V-2 DN41V RN1934V PN1832PN1847 DN1414 FN9803FN9980
01.13~01.19 1600 G16A GC416V-2 RN1934V PN1832PN1847 DN1414 FN9980
01.04~01.08 1600 G16AID GC416V RN1934V PN1832PN1847 DN1414 FN9980FN9803
01.08~ 1600 G16AID GC416V RHD RN1934V PN1832PN1847 DN1414 FN9980FN9803

SUZUKI   »   Super Carry

01.06~12.09 1500 G15A GC415T PN1832 DN1414
01.06~12.09 1600 G16A GC416T RN1934V PN1847PN1832 DN1414 FN9980
