ROTOR DISC » RN1882V

Specification

Type
Vented
Outter Ø
320
Num. of holes
5
Disc Thickness (Max)
28
Height
44
Centering Diameter
68
Pitch Circle Ø
114.3
Front/Rear
Front

Cross Reference

RENAULT
40 20 600 03R
RENAULT
40 20 641 55R
RENAULT
40 20 656 46R
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
11.12~03.19 1600 M5M 400 BHMM RN1882V PN0393 RN43004H PN0019W
09.12~08.16 1600 M5M 401 BHJ4 RS RN1882V PN0393 RN43004H PN0019W
03.15~ 1600 M5M 450 JRME RN1882V PN43003PN2804 RN2087H PN0730
03.15~ 1600 R9M JRA5 RN1882V PN43003PN2804 RN2087H PN0730
10.16~ 1800 M5P JRA5 RN1882V PN2804PN43003 RN2087H PN0730
10.18~ 2000 M9R650 JR RN1882V PN2804PN43003 RN2087H PN0730
09.16~ 1200 H5F R9 RN1882V PN2804PN43003 RN2286H PN0019WPN0730
09.16~ 1300 H5H450 R9A3 RN1882V PN43003 RN2286H PN0730
09.16~ 1500 K9K 647 R9A3 RN1882V PN2804PN43003 RN2286H PN0730
09.16~ 1500 K9K 649 R9A3 RN1882V PN43003PN2804 RN2286H PN0730
09.16~ 1600 R9M R9 RN1882V PN2804PN43003 RN2286H PN0730
11.08~02.12 2000 M9R 802 DT01 RN1882V PN0393 PN2702
01.11~07.15 2000 M9R857 KT19 EST EU LH RN1882V PN0393 RN43006H PN2702
03.08~07.15 3000 V9X LB/COUPE/ESTATE RN1882V PN0393 RN43006H PN2702
03.08~07.15 3500 V4Y 713 DT0C RN1882V PN0393 PN2702
08.10~08.15 3500 5ZV604 L43 RN1882V PN0393 RN43006H PN0521

Exemption from liability: the catalog data is advisory and can be used for reference only
