ROTOR DISC » RN1830V
Specification
Type
Vented
Outter Ø
297
Num. of holes
6
Disc Thickness (Max)
22
Height
70.2
Centering Diameter
108
Front/Rear
Front
Pitch Circle Ø
139.7
Drum Ø:
170
Disc Thickness (Min)
20
Structure Material
G3000
Cross Reference
TOYOTA
43512-04020
TOYOTA
43512-35280
TOYOTA
43512-35310
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 11.95~11.02 | 2700 | 3RZ-FE | RZN180L | RN1128VRN1830V | PN1219PN1387 | DN1214 | FN2305 | |
| 11.95~12.02 | 2700 | 3RZ-FE | RZN185 | RN1128VRN1830V | PN1219PN1387 | DN1214 | FN2305 | |
| 11.95~12.02 | 3000 | 1KZ-T | KZN185L | RN1830VRN1128V | PN1219 | DN1214 | FN2305 | |
| 11.95~08.02 | 3400 | 5VZ-FE | VZN180L | RN1830VRN1128V | PN1219PN1387 | DN1214 | FN0686FN2305 | |
| 11.95~12.02 | 3400 | 5VZ-FE | VZN185 | RN1128VRN1830V | PN1387PN1219 | DN1214 | FN2305 |
| 01.95~01.04 | 2700 | 3RZ-FE | RZN161 | RN1830V | ||||
| 01.94~01.04 | 2700 | 3RZ-FE | RZN171 | RN1830V | PN1830PN1219 | DN1214 | FN2305FN0686 | |
| 08.98~09.04 | 2700 | 3RZ-FE | RZN191 | RN1830V | PN1830 | DN1214 | FN2305FN0686 | |
| 02.98~09.04 | 2700 | 3RZ-FE | RZN196 | RN1830V | PN1830PN1219 | DN1214 | FN2305FN0686 | |
| 01.95~01.04 | 3400 | 5VZ-FE | VZN150 | RN1830V | DN1215 | |||
| 01.95~09.04 | 3400 | 5VZ-FE | VZN170 | RN1830VRN1128V | PN1219PN1830PN1387 | DN1214 | FN2305FN0686 | |
| 02.98~12.05 | 3400 | 5VZ-FE | VZN195L | RN1830V | PN1830PN1219PN1387 | DN1214 | FN0686FN2305 |
