ROTOR DISC » RN1774V

RN1774V

Specification

Type
Vented
Outter Ø
266
Num. of holes
6
Disc Thickness (Max)
20
Height
84
Centering Diameter
104
Pitch Circle Ø
126
Front/Rear
Front
Disc Thickness (Min)
18
Drum Ø:
167
Structure Material
G3000

Cross Reference

MITSUBISHI
MC112002
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MITSUBISHI   »   Canter

05.99~06.02 2800 4M40 FB51AB RN1774V PN3346PN3347 FN6655FN4447 FN6600
01.96~07.01 2800 4M40 FB631 RN1450VRN1774V PN3175
