ROTOR DISC » RN1450V

RN1450V

Specification

Type
Vented
Disc Thickness (Max)
20
Num. of holes
6
Height
46
Centering Diameter
104
Front/Rear
Front
Pitch Circle Ø
126
Outter Ø
266
Drum Ø:
155
Structure Material
G3000
Disc Thickness (Min)
18.4

Cross Reference

MITSUBISHI
MC838750
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MITSUBISHI   »   Canter

05.99~07.03 2000 4G63 FB500B RN1450V PN3346 FN4447 FN6600
10.93~04.99 2800 4M40 FB501B RN1450V PN3346 FN6655 FN6600
05.99~06.02 2800 4M40 FB50AB RN1450V PN3346 FN4447 FN6600
01.96~07.01 2800 4M40 FB631 RN1450VRN1774V PN3175
10.93~05.99 2800 4M40 FD501B RN1450V PN3346 FN6655 FN6600
