ROTOR DISC » RN2405V
Specification
Type
Vented
Outter Ø
252
Num. of holes
4
Hole Ø:
12.8
Disc Thickness (Max)
18
Disc Thickness (Min)
16
Height
48.7
Centering Diameter
62.2
Pitch Circle Ø
100
Drum Ø:
126
Front/Rear
Front
Structure Material
G3000
Cross Reference
HYUNDAI
51712-0X700
HYUNDAI
51712-B9000
HYUNDAI / KIA
51712-B4000
HYUNDAI / KIA
51712-K7700
KIA
51712-07700
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.19~01.23 | 1000 | G3LA | PHQ20 RHD HB | RN2405V | PN0858 | DN1447 | FN0609 | |
| 09.13~01.17 | 1200 | G4LA | PB414 RHD GRAND SDN | RN2405V | PN0858 | DN1447 | FN0609 |
| 01.17~01.20 | 1000 | G3LA | PB417 RHD GRAND | RN2405V | PN0858 | DN1447 | FN0609 | |
| 01.14~ | 1000 | G3LA | VTN | RN2405V | PN0858 | RN2629 | FN0609PN0538 | |
| 08.19~ | 1000 | G3LD | PGQ20 EU LHD | RN2405V | PN0858 | DN1447 | PN0538FN0609 | |
| 08.19~ | 1000 | G3LE | PGQ20 | RN2405V | PN6149 | RN2629 | PN0538 | |
| 01.18~ | 1200 | G4AG | HB GRAND | RN2405V | PN0858 | RN2629 | PN0538 | |
| 09.13~01.17 | 1200 | G4LA | B9 | RN2405V | PN0858 | DN1447 | FN0609 | |
| 09.13~01.17 | 1200 | G4LA | PB414 LHD GRAND HB | RN2405V | PN0858 | DN1447 | FN0609 | |
| 09.13~01.17 | 1200 | G4LA | PB414 LHD GRAND SDN | RN2405V | PN0858 | DN1447 | FN0609 | |
| 09.13~01.17 | 1200 | G4LA | PB414 RHD GRAND HB | RN2405V | PN0858 | DN1447 | FN0609 | |
| 09.13~01.17 | 1200 | G4LA | PB414 RHD HB | RN2405V | PN0858 | DN1447 | FN0609 | |
| 01.17~10.20 | 1200 | G4LA | PB417 RHD GRAND HB | RN2405V | PN0858 | DN1447 | FN0609 | |
| 01.17~10.20 | 1200 | G4LA | PB417 RHD GRAND SDN | RN2405V | PN0858 | DN1447 | FN0609 | |
| 09.16~12.19 | 1200 | G4LA | PB917 | RN2405V | PN0858 | RN2629 | PN0538 | |
| 08.19~01.23 | 1200 | G4LA | PHQ20 LHD GRAND | RN2405V | PN0858 | DN1447 | FN0609 | |
| 01.14~ | 1200 | G4LA | VTN | RN2405V | PN0858 | RN2629 | PN0538 |
