DRUM BRAKE » DN1447
Specification
Outter Ø
243
Num. of holes
4
Hole Ø
12.5
Centering Diameter
62.5
Height
57.6
Pitch Circle Ø
100
Drum Ø
203.2
Structure Material
G3000
Cross Reference
HYUNDAI
584111G000
HYUNDAI / KIA
58411-0X000
HYUNDAI / KIA
58411-1G000
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.05~08.11 | 1400 | G4EE | CM41 RHD | RN1370V | PN0435 | DN1447 | FN0617 | |
| 03.06~08.11 | 1400 | G4EE | CN31 RHD 3DR | RN1370V | PN0435 | RN1778DN1447 | FN0617PN0436 | FN0680 |
| 03.06~08.11 | 1400 | G4EE | MC | RN1370V | PN0435 | RN1778DN1447 | FN0617PN0436 | |
| 03.06~08.11 | 1500 | D4FA | MC | RN1370V | PN0435 | RN1778DN1447 | PN0436FN0609 | |
| 03.06~08.11 | 1600 | G4ED | CN41 SDN RHD | RN1370V | PN0435 | DN1447RN1778 | FN0617PN0436 | FN0680 |
| 03.06~08.11 | 1400 | G4EE | CM41 LHD | RN1370V | PN0435 | DN1447 | FN0617 | |
| 03.06~08.11 | 1500 | D4FA | MC | RN1370V | PN0435 | RN1778DN1447 | PN0436FN0617 | |
| 03.06~08.11 | 1600 | G4ED | HB LHD | RN1370V | PN0435 | RN1778DN1447 | PN0436FN0617 |
| 08.19~01.23 | 1000 | G3LA | PHQ20 RHD HB | RN2405V | PN0858 | DN1447 | FN0609 | |
| 09.13~01.17 | 1200 | G4LA | PB414 LHD GRAND HB | RN2405V | PN0858 | DN1447 | FN0609 | |
| 09.13~01.17 | 1200 | G4LA | PB414 RHD GRAND SDN | RN2405V | PN0858 | DN1447 | FN0609 | |
| 01.23~ | 1200 | G4LA | PHQ23 RHD GRAND | RN11001V | PN6151 | DN1447 | FN0609 |
| 01.17~01.20 | 1000 | G3LA | PB417 RHD GRAND | RN2405V | PN0858 | DN1447 | FN0609 | |
| 08.19~ | 1000 | G3LD | PGQ20 EU LHD | RN2405V | PN0858 | DN1447 | PN0538FN0609 | |
| 09.10~01.16 | 1100 | G4HG | AM51B LHD | RN11001V | PN0448 | DN1447 | FN11186 | |
| 09.10~01.16 | 1100 | G4HG | AM51B RHD | RN11001V | PN0448 | DN1447 | FN11186 | |
| 01.07~09.10 | 1100 | G4HG | AN51B | RN11001V | PN0448 | DN1447 | FN11186 | |
| 01.08~01.14 | 1100 | G4HG | HB LHD | RN11001V | PN0448 | DN1447 | FN11186 | |
| 09.13~01.17 | 1200 | G4LA | B9 | RN2405V | PN0858 | DN1447 | FN0609 | |
| 10.07~09.10 | 1200 | G4LA | PA07 | RN11001V | PN0448PN0438 | RN1791DN1447 | FN0609FN11186PN0526 | |
| 09.10~09.13 | 1200 | G4LA | PA07 | RN11001V | PN0448 | RN1791DN1447 | PN0526FN11186FN0609 | |
| 09.13~01.17 | 1200 | G4LA | PB414 LHD GRAND SDN | RN2405V | PN0858 | DN1447 | FN0609 | |
| 09.13~01.17 | 1200 | G4LA | PB414 RHD GRAND HB | RN2405V | PN0858 | DN1447 | FN0609 | |
| 09.13~01.17 | 1200 | G4LA | PB414 RHD HB | RN2405V | PN0858 | DN1447 | FN0609 | |
| 01.17~10.20 | 1200 | G4LA | PB417 RHD GRAND HB | RN2405V | PN0858 | DN1447 | FN0609 | |
| 01.17~10.20 | 1200 | G4LA | PB417 RHD GRAND SDN | RN2405V | PN0858 | DN1447 | FN0609 | |
| 08.19~01.23 | 1200 | G4LA | PHQ20 LHD GRAND | RN2405V | PN0858 | DN1447 | FN0609 |
| 03.12~12.15 | 1200 | G4LA | BA51 5DR RHD | RN2606V | PN0448 | DN1447 | FN0609 | |
| 10.08~12.12 | 1200 | G4LA | PB08 5DR RHD | RN2606V | PN0448 | DN1447 | FN0609 | FN0661 |
| 10.08~06.12 | 1200 | G4LA | PBT10 LHD | RN2606V | PN0448 | DN1447 | FN0609 | |
| 01.10~06.12 | 1200 | G4LA | PBT10 LHD | RN2606V | PN0448 | DN1447 | FN0609 | |
| 06.12~12.14 | 1200 | G4LA | PBT12 LHD | RN2606V | PN0448 | DN1447 | FN0609 | FN0661 |
| 06.12~12.14 | 1200 | G4LA | PPB12 LHD | RN2606V | PN0448 | DN1447 | FN0609 |
| 11.05~09.11 | 1400 | G4EE | DE22 | RN1370V | PN0435 | RN1778DN1447 | PN0436FN0617 | FN0680 |
| 01.05~09.11 | 1400 | G4EE | DE24 | RN1370V | PN0435 | DN1447 | FN0617 | |
| 03.05~01.12 | 1400 | G4EE | DF41 SDN LHD | RN1370V | PN0435 | DN1447RN1778 | FN0617PN0436 | |
| 09.09~08.11 | 1400 | G4EE | DG41 SDN RHD | RN1370V | PN0435 | DN1447 | FN0617 | |
| 09.06~10.10 | 1400 | G4EE | DH41 SDN RHD | RN1370V | PN0435 | DN1447RN1778 | PN0436FN0617 | |
| 03.05~01.12 | 1400 | G4EE | DH51 HB RHD | RN1370V | PN0435 | DN1447 | FN0617 | |
| 03.05~01.12 | 1400 | G4EE | HB LHD | RN1370V | PN0435 | DN1447 | FN0617 | |
| 03.05~09.09 | 1500 | D4FA | TC05 HB LHD | RN1370V | PN0435 | DN1447 | PN0436FN0617 | |
| 11.05~09.11 | 1600 | G4ED | DE22 | RN1370V | PN0435 | RN1778DN1447 | PN0436FN0617 | FN0680 |
| 01.05~09.11 | 1600 | G4ED | DE24 | RN1370V | PN0435 | DN1447 | FN0617 |
