ROTOR DISC » RN1617V
Specification
Type
Vented
Outter Ø
296
Num. of holes
5
Disc Thickness (Max)
28
Height
49.2
Centering Diameter
62
Pitch Circle Ø
114.3
Front/Rear
Front
Drum Ø:
144
Disc Thickness (Min)
25
Structure Material
G3000
Cross Reference
TOYOTA
43512-28190
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 04.08~01.15 | 2400 | 2AZ-FE | ANH20R | RN1617V | PN1527 | RN1670 | PN1239 | FN0567 |
| 04.08~01.15 | 2400 | 2AZ-FE | ANH20W | RN1617VRN1443V | PN1845PN1527 | RN1670 | PN1239 | FN0567 |
| 04.08~01.15 | 2400 | 2AZ-FE | ANH25W | RN1617V | PN1527 | RN1670 | PN1239 | FN0567 |
| 11.11~01.15 | 2400 | 2AZ-FXE | ATH20W | RN1617V | PN1527 | RN1670 | PN1239 | FN0567 |
| 01.15~ | 2500 | 2AR-FE | AGH30R | RN1617V | PN1527 | RN1968V | PN1852 | |
| 01.15~ | 2500 | 2AR-FE | AGH30W | RN1617V | PN1527 | RN1968V | PN1852 | |
| 01.15~ | 2500 | 2AR-FE | AGH35W | RN1617V | PN1527 | RN1968V | PN1852 | |
| 01.15~06.23 | 2500 | 2AR-FXE | AYH30W | RN1617V | PN1527 | RN1968V | PN1852 | |
| 06.10~01.15 | 3500 | 2GR-FE | GGH20L | RN1617V | PN1527 | RN1670 | PN1239 | FN0567 |
| 04.08~01.15 | 3500 | 2GR-FE | GGH20W | RN1617V | PN1527 | RN1670 | PN1239 | FN0567 |
| 04.08~01.15 | 3500 | 2GR-FE | GGH25W | RN1617V | PN1527 | RN1670 | PN1239 | FN0567 |
| 01.15~ | 3500 | 2GR-FE | GGH30W | RN1617V | PN1527 | RN1968V | PN1852 | |
| 01.15~ | 3500 | 2GR-FE | GGH35W | RN1617V | PN1527 | RN1968V | PN1852 |
| 01.06~10.19 | 2400 | 2AZ-FE | ACR50W | RN1617V | PN1527 | RN1616 | PN1239 | FN0567 |
| 06.06~10.19 | 2400 | 2AZ-FXE | AHR20W | RN1617V | PN1527 | RN1616 | PN1239 | |
| 01.06~05.16 | 3500 | 2GR-FE | GSR50W | RN1617V | PN1527 | RN1616 | PN1239 | FN0567 |
| 01.06~12.08 | 3500 | 2GR-FE | GSR55W | RN1617V | PN1527 | RN1616 | PN1239 | FN0567 |
