NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1616

ROTOR DISC » RN1616

Specification

Type

Solid

Outter Ø

298

Num. of holes

5

Disc Thickness (Max)

10

Height

64.4

Centering Diameter

62

Pitch Circle Ø

114.3

Front/Rear

Rear

Drum Ø:

190

Disc Thickness (Min)

8.4

Structure Material

G3000

Cross Reference

TOYOTA

42431-28130

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Estima

01.06~12.08

2400

2AZ-FE

ACR55W

RN1617V

PN1527

RN1616

PN1239

FN0567

TOYOTA » Estima Emina

01.06~10.19	2400	2AZ-FE	ACR50W	RN1617V	PN1527	RN1616	PN1239	FN0567
06.06~10.19	2400	2AZ-FXE	AHR20W	RN1617V	PN1527	RN1616	PN1239
01.06~05.16	3500	2GR-FE	GSR50W	RN1617V	PN1527	RN1616	PN1239	FN0567
01.06~12.08	3500	2GR-FE	GSR55W	RN1617V	PN1527	RN1616	PN1239	FN0567

TOYOTA » Previa

01.06~10.19	2400	2AZ-FE	ACR50L	RN1617V	PN1527	RN1616	PN1239	FN0567
01.06~	2400	2AZ-FE	ACR50R	RN1617V	PN1527	RN1616	PN1239	FN0567
11.06~10.19	3500	2GR-FE	GSR50L	RN1617V	PN1527	RN1616	PN1239	FN0567
11.06~01.18	3500	2GR-FE	GSR50R	RN1617V	PN1527	RN1616	PN1239	FN0567

TOYOTA » Tarago

01.06~	2400	2AZ-FE	ACR50L	RN1617V	PN1527	RN1616	PN1239
01.06~	2400	2AZ-FE	ACR50R	RN1617V	PN1527	RN1616	PN1239	FN0567
