ROTOR DISC » RN1613V

Specification

Type
Vented
Outter Ø
261
Num. of holes
6
Disc Thickness (Max)
24
Height
24
Centering Diameter
86
Pitch Circle Ø
108
Front/Rear
Front
Drum Ø:
154
Disc Thickness (Min)
22
Structure Material
G3000

Cross Reference

KIA
0K60A33251A
MAZDA
SG37-33-251A
MAZDA
SG38-33-251A
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.03~09.07 2500 D4BH (4D56) SD RN1613V PN0433 DN1479 FN3350
09.99~10.05 2700 J2 SD RN1613V PN0433 DN1519DN1505 FN3350
01.04~11.06 2700 J2 SE0 RN1613V PN0433 DN1479 FN0814
01.04~11.06 2700 J2 SE9 RN1613V PN0433 DN1479 FN0814
03.14~12.16 2700 J2 SGX7 RN1613V PN0433 DN1479 FN0814
01.20~ 2700 J2 SGY7 DBL LHD RN1613V PN0433 DN1479 FN0814
01.20~ 2700 J2 SJZ7 SPR LHD RN1613V PN0433 DN1479 FN0814
11.96~12.98 2500 WL SDY RN1613VRN1806V PN5211 FN3350FN3348FN3349

Exemption from liability: the catalog data is advisory and can be used for reference only
