ROTOR DISC » RN1608V

RN1608V

Specification

Type
Vented
Outter Ø
255
Num. of holes
4
Disc Thickness (Max)
20
Height
46.2
Centering Diameter
55
Pitch Circle Ø
100
Front/Rear
Front
Disc Thickness (Min)
18
Drum Ø:
131
Structure Material
G3000

Cross Reference

TOYOTA
43512-74010
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   iQ

11.08~03.16 1000 1KR-FE KGJ10 RN1608V PN1472 DN1273RN1310 FN2401PN1519
11.08~05.14 1000 1KR-FE KGJ10L RN1608V PN1472 RN1310DN1273 FN2401PN1519
05.09~03.16 1300 1NR-FE NGJ10 RN1608V PN1472 RN1310DN1273 FN2401PN1519
11.08~05.12 1400 1ND-TV NUJ10L RN1608V PN1472 RN1310DN1273 FN2401FN2342PN1519

TOYOTA   »   Scion IQ

05.11~06.15 1300 1NR-FE NGJ10L RN1608V PN1472 DN1273 FN2401

TOYOTA   »   Vitz

10.10~05.12 1000 1KR-FE KSP130 RN1608VRN1309V PN1472PN1508 DN1273DN1220 FN2401
01.10~ 1300 1NR-FE NSP130 RN1608V PN1472 DN1273DN1220 FN2401
