ROTOR DISC » RN1553V
Specification
Type
Vented
Outter Ø
312
Num. of holes
6
Disc Thickness (Max)
18
Height
68
Centering Diameter
108
Front/Rear
Rear
Pitch Circle Ø
139.7
Drum Ø:
210
Disc Thickness (Min)
16
Structure Material
G3000
Variation
Cross Reference
TOYOTA
42431-0K230
TOYOTA
42431-60311
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 11.09~08.11 | 2700 | 2TR-FE | TRN280L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.09~05.15 | 4000 | 1GR-FE | GRN280L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.09~08.19 | 4000 | 1GR-FE | GRN285L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 01.06~07.14 | 4000 | 1GR-FE | GSJ10L | RN1446V | PN1482 | RN1216VRN1553V | PN1243 | FN0642 |
| 11.10~01.18 | 4000 | 1GR-FE | GSJ15W | RN1446V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.22~ | 2400 | 2GD-FTV | GUN155L | RN1319VRN1945V | PN1872 | RN1216VRN1553V | PN1243PN1846 | FN0642 |
| 01.16~ | 2400 | 2GD-FTV | GUN155R | RN1319VRN1945V | PN1872 | RN1553VRN1216V | PN1243PN1846 | FN0642 |
| 07.15~04.21 | 2400 | 2GD-FTV | GUN165R | RN1319V | PN1872 | RN1553V | PN1243 | FN0642 |
| 03.16~ | 2400 | 2GD-FTV | GUN166R | RN1319V | PN1872 | DN1102RN1553V | FN0620PN1846PN1243 | FN0642 |
| 01.16~ | 2700 | 2TR-FE | TGN156L | RN1945V | PN1872 | DN1102RN1216VRN1553V | PN1846FN0620PN1243 | FN0642 |
| 05.16~ | 2700 | 2TR-FE | TGN156R | RN1945V | PN1872 | RN1553V | PN1846FN0620PN1243 | FN0642 |
| 01.16~ | 2700 | 2TR-FE | TGN166L | RN1945V | PN1872 | DN1102RN1553VRN1216V | FN0620PN1243PN1846 | FN0642 |
| 01.16~ | 2700 | 2TR-FE | TGN166R | RN1945V | PN1872 | RN1553V | FN0620PN1846PN1243 | FN0642 |
| 07.15~ | 2800 | 1GD-FTV | GUN156R | RN1945V | PN1872 | RN1553V | PN1243PN1846 | FN0642 |
| 08.09~ | 2700 | 2TR-FE | TRJ150L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.09~ | 2700 | 2TR-FE | TRJ150W | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 06.15~ | 2800 | 1GD-FTV | GDJ150 | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 06.15~ | 2800 | 1GD-FTV | GDJ150L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 06.15~ | 2800 | 1GD-FTV | GDJ151W | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 06.15~ | 2800 | 1GD-FTV | GDJ155 | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.09~08.17 | 3000 | 1KD-FTV | KDJ150L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.17~ | 3000 | 1KD-FTV | KDJ150L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.09~08.17 | 3000 | 1KD-FTV | KDJ150R | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.13~ | 3000 | 1KD-FTV | KDJ155L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.09~ | 3000 | 5L-E | LJ150 | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 06.09~ | 4000 | 1GR-FE | GRJ150L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 01.09~ | 4000 | 1GR-FE | GRJ150R | RN1435V | PN1482 | RN1553V | PN1243 | |
| 08.09~ | 4000 | 1GR-FE | GRJ150W | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 09.09~ | 4000 | 1GR-FE | GRJ151W | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
