ROTOR DISC » RN1435V
Specification
Type
Vented
Disc Thickness (Max)
32
Num. of holes
6
Height
68.6
Centering Diameter
108
Front/Rear
Front
Outter Ø
338
Pitch Circle Ø
139.7
Drum Ø:
171
Disc Thickness (Min)
29
Structure Material
G3000
Variation
Cross Reference
TOYOTA
43512-60190
TOYOTA
43512-60191
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 11.09~08.11 | 2700 | 2TR-FE | TRN280L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.09~05.15 | 4000 | 1GR-FE | GRN280L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.09~08.19 | 4000 | 1GR-FE | GRN285L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.09~ | 2700 | 2TR-FE | TRJ150L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.09~ | 2700 | 2TR-FE | TRJ150W | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 06.15~ | 2800 | 1GD-FTV | GDJ150 | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 06.15~ | 2800 | 1GD-FTV | GDJ150L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 06.15~ | 2800 | 1GD-FTV | GDJ151W | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 06.15~ | 2800 | 1GD-FTV | GDJ155 | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.13~ | 3000 | 1KD-FTV | KDJ150G | RN1435V | PN1482 | PN1243 | ||
| 08.09~08.17 | 3000 | 1KD-FTV | KDJ150L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.17~ | 3000 | 1KD-FTV | KDJ150L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.09~08.17 | 3000 | 1KD-FTV | KDJ150R | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.13~ | 3000 | 1KD-FTV | KDJ155L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 08.09~ | 3000 | 5L-E | LJ150 | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 06.09~ | 4000 | 1GR-FE | GRJ150L | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 01.09~ | 4000 | 1GR-FE | GRJ150R | RN1435V | PN1482 | RN1553V | PN1243 | |
| 08.09~ | 4000 | 1GR-FE | GRJ150W | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
| 09.09~ | 4000 | 1GR-FE | GRJ151W | RN1435V | PN1482 | RN1553V | PN1243 | FN0642 |
