ROTOR DISC » RN22004V

Specification

Type
Vented
Outter Ø
237
Num. of holes
4
Disc Thickness (Max)
22
Height
43.7
Centering Diameter
61
Front/Rear
Front
Pitch Circle Ø
100
Disc Thickness (Min)
20
Drum Ø:
128
Structure Material
G3000

Cross Reference

NISSAN
40206-AX000
NISSAN
40206-CT40A
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.02~11.08 1400 CR14DE BNZ11 RN22004V PN2452 FN1198FN1264
10.02~11.08 1400 CR14DE BZ11 RN22004V PN2452 DN1314 FN1261
05.05~11.08 1500 HR15DE YZ11 RN22004V PN2452 DN1314 FN1261
04.06~06.08 1500 HR15DE SC11 RHD RN22004VRN1995V PN2452 DN1293 FN1267
04.06~06.08 1600 HR16DE SC11 RN22004VRN1995V PN2452 DN1319DN1293 FN1267
02.02~10.03 1000 CR10DE K12 JPN RN22004V PN2452 DN1314 FN1261
02.02~07.10 1200 CR12DE AK12 RN22004VRN22003V PN2452 DN1314 FN1261
02.02~06.07 1400 CR14DE BK12 RN22004V PN2452 DN1314 FN1261
09.02~07.10 1400 CR14DE BNK12 RN22004V PN2452 FN1264FN1198
02.02~08.10 1400 CR14DE K12 RN22004VRN1187V PN2800PN2452 DN1314 FN1261FN1255
08.05~07.10 1500 HR15DE YK12 RN22004V PN2452 DN1314 FN1261
01.05~09.12 1500 HR15DE E11 RN22004V PN2452 DN1314 FN1261
01.05~09.12 1500 HR15DE NE11 RN22004V PN2452 FN1264
01.06~08.13 1600 HR16DE E11E RN22004VRN1187V PN2800 DN1611HDN1611 FN1255
10.08~09.12 1600 HR16DE ZE11 RN22004V PN2452 DN1611DN1611H FN1261
09.04~06.08 1500 HR15DE C11 RN22004VRN1995V PN2452 DN1293 FN1267
09.04~06.09 1500 HR15DE C11 RN22004V PN2452 FN1267
04.06~06.08 1600 HR16DE C11 RN1995VRN22004V PN2452 DN1293 FN1267
10.04~07.09 1500 HR15DE SC11 JPN RN22004V PN2452 FN1267
09.08~06.09 1600 HR16DE SZC11 RN22004V PN2452 FN1267
01.05~06.09 1800 MR18DE SJC11 RN22004VRN22003V PN0397PN2452 DN1319 FN1267PN2466

Exemption from liability: the catalog data is advisory and can be used for reference only
