DRUM BRAKE » DN1293

Specification

Outter Ø
239
Num. of holes
4
Hole Ø
12.8
Centering Diameter
114.3
Height
65.9
Pitch Circle Ø
114.3
Drum Ø
203
Structure Material
G3000

Cross Reference

NISSAN
43206-EE310
NISSAN
43206-EL00A
NISSAN
D3206-EL00JNW
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
04.06~07.12 1500 HR15DE SC11 RHD RN1995VRN22004V PN2452 DN1293 FN1267
04.06~07.12 1600 HR16DE SC11 RN22004VRN1995V PN2452 DN1293DN1319 FN1267
06.08~07.12 1800 MR18DE SC11 RN1995V PN2452 DN1293 FN1267
10.07~03.14 1600 HR16DE L10S RN1995V PN2452 DN1294DN1293 FN1264FN1267
08.08~03.14 1600 HR16DE NL10S RN1995V PN2452 DN1293 FN1267
01.09~01.12 1600 K4M L10B RN1995V PN2452 DN1293 FN1267
01.12~10.14 1600 K4M L10BB RN1995V PN2452 DN1293 FN1267
01.09~01.12 1800 MR18DE L10B RN1995V PN2452 DN1293DN1294 FN1264FN1267
01.12~10.14 1800 MR18DE L10BB RN1995V PN2452 DN1294DN1293 FN1267FN1264
01.14~02.17 1600 HR16DE L11W RN1995V PN2452 DN1293 FN1267
02.17~08.20 1600 HR16DE L11WW RN1995V PN2452 DN1293 FN1267
09.04~06.12 1500 HR15DE C11 RN1995VRN22004V PN2452 DN1293 FN1267
04.06~06.12 1600 HR16DE C11 RN22004VRN1995V PN2452 DN1293 FN1267
06.06~04.13 1800 MR18DE C11X RN1995VRN1424V PN2452PN2201 DN1293RN1933DN1294 FN1264PN2466FN1267 FN0621
01.05~08.12 1800 MR18DE JC11 RN22003VRN1995V PN2452 DN1293 FN1267
06.08~07.12 1800 MR18DE SC11 RN1995V PN2452 DN1293 FN1267

Exemption from liability: the catalog data is advisory and can be used for reference only
