ROTOR DISC » RN2329

Specification

Type
Solid
Outter Ø
295
Num. of holes
5
Hole Ø:
15
Disc Thickness (Max)
9.5
Disc Thickness (Min)
8.5
Height
32.1
Centering Diameter
68.6
Pitch Circle Ø
114.3
Drum Ø:
151.5
Front/Rear
Rear
Structure Material
G3000

Cross Reference

GREAT WALL
3502102XGW02A
HAVAL
3502102XGW02A
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
04.21~ 1500 GW4G15K RN2327V PN6025 RN2329 PN6026

Exemption from liability: the catalog data is advisory and can be used for reference only
