ROTOR DISC » RN2328V

RN2328V

Specification

Type
Vented
Front/Rear
Front
Structure Material
G3000
Outter Ø
320
Num. of holes
5
Hole Ø:
15
Disc Thickness (Max)
22
Disc Thickness (Min)
20
Height
38
Centering Diameter
68.5
Pitch Circle Ø
114.3
Drum Ø:
146.5

Cross Reference

GREAT WALL
3501100XGW02A
HAVAL
3501100XGW02A
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HAVAL   »   Jolion

04.21~ 1500 GW4B15D RN2328V PN6023 RN2330 PN6045
