ROTOR DISC » RN2292

Specification

Type
Solid
Outter Ø
304
Num. of holes
5
Hole Ø:
13.1
Disc Thickness (Max)
12
Disc Thickness (Min)
9.6
Height
57.1
Centering Diameter
64
Pitch Circle Ø
114.3
Drum Ø:
155
Front/Rear
Rear
Structure Material
G3000

Cross Reference

GREAT WALL
3502011XKY00A
HAVAL
3502011XKY00A
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
12.18~ 1500 GW4B15 RN2291V PN8802 RN2292 PN6016
12.18~ 2000 GW4C20 RN2291V PN8802 RN2292 PN6016
01.21~ 1500 GW4G15F RN1415V PN8802 RN2292 PN6016

Exemption from liability: the catalog data is advisory and can be used for reference only
