ROTOR DISC » RN2284VL

Specification

Type
Vented
Outter Ø
330
Num. of holes
5
Hole Ø:
16.5
Disc Thickness (Max)
20
Disc Thickness (Min)
18.4
Height
64.2
Centering Diameter
67
Pitch Circle Ø
112
Front/Rear
Rear
Structure Material
G3000
Drum Ø:
187

Cross Reference

BMW
34 21 6 882 245
TOYOTA
42431-WAA02
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
07.16~09.19 2000 B47D20 G30 RN2262V PN0577 RN2284VLRN2284VR PN0546
07.16~09.19 2000 B48B20A G30 RN2262V PN0577 RN2284VLRN2284VR PN0546
01.17~12.20 2000 B48B20A G30 SG RN2262V PN0577 RN2284VLRN2284VR PN0546
04.18~ 2000 B48B20A G01 RN2262V PN0577 RN2284VLRN2284VR PN0546
04.18~ 2000 B48B20A G02 RN2262V PN0577 RN2284VRRN2284VL PN0546
04.18~ 2000 B48D G02 RN2262V PN0577 RN2284VLRN2284VR PN0546

Exemption from liability: the catalog data is advisory and can be used for reference only
