ROTOR DISC » RN2242V

Specification

Type
Vented
Outter Ø
320
Num. of holes
5
Hole Ø:
15.3
Disc Thickness (Max)
24
Disc Thickness (Min)
21.4
Height
48.5
Centering Diameter
69
Pitch Circle Ø
112
Drum Ø:
152.3
Front/Rear
Rear
Structure Material
G3000

Cross Reference

MERCEDES-BENZ
000 423 07 12
MERCEDES-BENZ
A 000 423 07 12
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
04.16~ 3000 M 276.823 C205 PN0695 RN2242V PN0746
04.16~05.18 3000 M 276.823 W205 PN0695 RN2242V PN0746PN0575W
12.17~ 3000 OM 656.929 C257 PN0695 RN2242V PN31031
12.17~ 3000 OM 656.929 C257 PN0695 RN2242V PN31031
08.15~ 2200 OM 651.921 X253 RN2241V PN0585 RN2242V PN0746
08.15~ 2000 M 274.920 C253 RN2241V PN0695 RN2242V PN0746
08.15~ 2000 M 274.920 X253 RN2241V PN0695 RN2242V PN0746
08.15~ 2200 OM 651.921 X253 RN2241V PN0585PN0695 RN2242V PN0746
08.15~ 2000 M 274.920 X253 RN2241V PN0585PN0790 RN2242V PN0746
08.19~ 3000 OM 654.920 C253 PN0695 RN2242V PN0746
01.16~ 2000 M 274.920 X253 RN2241V PN0695PN0790 RN2242V PN0746
11.15~ 3000 M 276.823 X253 PN0695 RN2242V PN0746

Exemption from liability: the catalog data is advisory and can be used for reference only
