ROTOR DISC » RN2201

Specification

Type
Solid
Outter Ø
320
Num. of holes
5
Disc Thickness (Max)
12
Disc Thickness (Min)
10
Height
44
Centering Diameter
67
Pitch Circle Ø
112
Structure Material
G3000
Drum Ø:
157
Hole Ø:
15.3
Front/Rear
Rear

Cross Reference

MERCEDES-BENZ
A 247 423 03 12
MERCEDES-BENZ
A247423031207
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.18~ 2000 M 260.920 W177 PN0763 RN2201 PN0758
07.19~ 2000 M 133.980 W177 PN0763PN0944 RN2201 PN0758
12.21~ 780.200,780.500 X243 RN2444V PN0763 RN2201 PN0758
12.21~ 780.200,780.500 X243 RN2444V PN0763 RN2201 PN0758
02.20~ 2000 M 260.920 H247 RN2500DRN2444V PN0763 RN2201 PN0758
08.19~ 2000 M 260.920 X247 RN2444VRN2500D PN0763 RN2201 PN0758

Exemption from liability: the catalog data is advisory and can be used for reference only
