ROTOR DISC » RN2196V

Specification

Type
Vented
Outter Ø
318
Num. of holes
5
Disc Thickness (Max)
30
Disc Thickness (Min)
28
Height
51
Centering Diameter
67
Pitch Circle Ø
112
Structure Material
G3000
Drum Ø:
154.5
Hole Ø:
15.3
Front/Rear
Front

Cross Reference

MERCEDES-BENZ
A 247 421 07 12
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
02.20~ 1300 M 282 914 H247 RN2196V PN31027 RN2197 PN0966

Exemption from liability: the catalog data is advisory and can be used for reference only
