DRUM BRAKE » DN1841

Specification

Outter Ø
242
Num. of holes
4
Hole Ø
14.5
Centering Diameter
57
Height
65.5
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000

Cross Reference

GM
568039
GM
568054
GM
568057
GM
90168958
GM
91024352
GM
96175281
OPEL
05 68 057
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
04.05~06.09 1500 A15SMS T100 (UKR) RN1206V PN0390 DN1678DN1841 FN11622
07.97~06.02 1300 A13SM KLAT PN0021 DN1678DN1841 FN11622
07.97~12.10 1400 A14SMS KLAT PN0390PN0374PN0234 DN1678DN1841 FN11622
08.97~06.99 1500 A15SMS KLAT PN0390 DN1678DN1841 FN11622
04.97~06.99 1500 Y15L KLAT PN0021 DN1841DN1678 FN11622
08.97~06.02 1500 YA15SM KLAT PN0234PN0374 DN1841DN1678 FN11622
07.97~12.10 1600 A16DMS KLAT RN1017VRN1206V PN0031PN0374 DN1841DN1678 FN11622
08.02~01.08 1500 A15MF N100 RN1206V PN0234 DN1841 FN11622
01.08~08.16 1500 A15SMS N150 RN1206V PN0234PN0390 DN1841 FN11622
01.95~01.08 1500 G15MF N100 RN1206V PN0234 DN1841 FN11622
01.08~08.16 1500 Y15L N150 PN0374PN0234 DN1841 FN11622
01.08~08.16 1600 F16D3 N150 PN0374 DN1841 FN11622
02.97~04.99 1600 A16DMS/L44 KLAJ RN2098V PN0374 DN1841RN2099 FN11622PN0424

Exemption from liability: the catalog data is advisory and can be used for reference only
