DRUM BRAKE » DN1711

DN1711

Specification

Outter Ø
249.5
Num. of holes
4
Hole Ø
13.2
Centering Diameter
59
Height
61
Pitch Circle Ø
139,7
Drum Ø
203.3
Structure Material
G3000

Cross Reference

FIAT
51822458
FIAT
51904079
FIAT
51904681
FIAT
51916180
FIAT
51945971
FIAT
51962845
FIAT
60813016
FIAT
7774593
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHRYSLER   »   Ypsilon

05.11~12.18 900 312 A2.000 846 RN1068V PN41005 DN1711 FN0682

FIAT   »   Fiorino

10.09~ 1400 350 A1.000 LCVs RN1068V PN0211W DN1711 FN0682
01.08~ 1400 KFT LCVs RN1068V PN0211W DN1711 FN0682

FIAT   »   Idea

01.03~01.08 1400 843 A1.000 135.512.0.0 RN1068V PN0211W DN1711 FN0682

FIAT   »   Nuova Panda

02.12~02.16 1200 1074374 312 PN41005 DN1711 FN0682

FIAT   »   Panda

09.03~08.13 1100 187 A1.000 169A RN1068V PN0287WPN0211W DN1710DN1711RN1385 FN0616FN0774FN0682PN0192FN0586
02.12~02.16 1200 1074374 312 PN41005 DN1711 FN0682
03.10~08.13 1200 169 A4.000 169A RN1068V PN0211WPN0287W RN1385DN1710DN1711 FN0616FN0774FN0682PN0192FN0586
12.03~12.06 1300 188 A9.000 169A RN1068V PN0211WPN0287W RN1385DN1710DN1711 FN0586FN0616FN0774FN0682PN0192
10.06~08.13 1400 169 A3.000 169A RN1068V PN0211WPN0287W DN1710DN1711RN1385 FN0586FN0616PN0192FN0774FN0682

FIAT   »   Qubo

01.07~01.16 1400 KFV 3002P1051870 RN1068V PN0211W DN1711 FN0682

LANCIA   »   Musa

09.04~ 1400 DN1711
04.06~ 1400 DN1711
