DRUM BRAKE » DN1680
Specification
Outter Ø
230
Num. of holes
4
Hole Ø
12.5
Centering Diameter
57
Height
56.9
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000
Cross Reference
GM
19287526
GM
96470999
GM
96471771
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.05~01.08 | 1400 | F14D3 / L14 | 3DR HB CH | RN1206V | PN0370 | DN1680 | FN11174 | |
| 03.02~02.08 | 1500 | F15S3 / LX6 | SA48 5DR HB RHD | RN1206V | PN0370 | DN1680DN1668 | FN11174 | |
| 03.02~02.08 | 1500 | F15S3 / LX6 | SF69 | RN1206V | PN0370 | DN1680DN1668 | FN11174 | |
| 03.02~02.08 | 1500 | F15S3 / LX6 | TM62 5DR HB | RN2117V | PN0374 | DN1680 | FN11174 |
| 03.05~01.12 | 1400 | F14D3 / L14 | SA69 GEN | RN1206V | PN0370 | DN1680 | FN11174 | |
| 03.05~01.12 | 1400 | F14D3 / L14 | SF48 | RN1206V | PN0370PN0374 | DN1680 | FN11174 | |
| 03.05~01.12 | 1400 | F14D3 / L14 | SF69 | RN2117VRN1206V | PN0374PN0370 | DN1680 | FN11174 | |
| 12.07~01.12 | 1400 | F14D3 / L95 | SA69 EUR | RN1206V | PN0370 | DN1680 | FN11174 | |
| 12.07~01.12 | 1400 | F14D3 / L95 | SA69 GEN SDN | RN1206V | PN0370 | DN1680 | FN11174 |
| 01.08~01.12 | 1200 | B12D1 / LMU | SDN LHD | RN1206V | PN0370 | DN1680 | FN11174 | |
| 12.07~01.13 | 1400 | F14D3 / L95 | SA48 | RN1206V | PN0374PN0370 | DN1680 | FN11174 | |
| 12.07~01.13 | 1400 | F14D3 / L95 | TJ63 HB LHD | RN1206V | PN0370 | DN1680 | FN11174 | |
| 12.07~01.13 | 1400 | F14D4 / LDT | HB CHL | RN1206V | PN0374PN0370 | DN1680 | FN11174 | |
| 01.08~01.13 | 1500 | F15S | R69 | RN2117VRN1206V | PN0374PN0370 | DN1680 | FN11174 | |
| 01.08~01.13 | 1500 | F15S3 / LX6 | SA48 HB LHD | RN1206V | PN0370PN0374 | DN1680 | FN11174 | |
| 01.08~01.13 | 1500 | F15S3 / LX6 | TM63 HB RHD | RN2117VRN1206V | PN0370PN0374 | DN1680 | FN11174 | |
| 01.08~01.13 | 1500 | LV8 | SDN VTN | RN1206V | PN0370PN0374 | DN1680 | FN11174 |
| 01.10~01.16 | 1000 | B10D1 | MA48 | RN1206V | PN0570 | DN1680 | FN11174 | |
| 01.13~01.16 | 1000 | LFM / B10D2 | RCE48 LHD | RN1206V | PN0570 | DN1680 | ||
| 01.10~01.16 | 1000 | LMT / B10D1 | 1C#48 | RN1206V | PN0570 | DN1680 | FN11174 | |
| 01.11~01.21 | 1200 | B12D1 / LMU | 1C#48 LHD | RN1206V | PN0570 | DN1680 | FN11174 | |
| 01.12~01.16 | 1200 | B12D1 / LMU | CT48 RHD | RN1206V | PN0570 | DN1680 | FN11174 | |
| 01.12~01.16 | 1200 | LL0 | CV48 | RN2117V | PN0374 | DN1680 | FN11174 |
