ROTOR DISC » RN2117V

Specification

Type
Vented
Outter Ø
256
Num. of holes
6
Disc Thickness (Max)
24
Disc Thickness (Min)
22
Height
41
Centering Diameter
59
Pitch Circle Ø
100
Drum Ø:
123
Front/Rear
Front
Structure Material
G3000

Cross Reference

DAEWOO
96471275
GM
96471275
GM
96534660
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.02~02.08 1500 F15S3 / LX6 TM62 5DR HB RN2117V PN0374 DN1680 FN11174
03.05~01.12 1400 F14D3 / L14 SF69 RN2117VRN1206V PN0374PN0370 DN1680 FN11174
01.08~01.13 1500 F15S R69 RN1206VRN2117V PN0370PN0374 DN1680 FN11174
01.08~01.13 1500 F15S3 / LX6 TM63 HB RHD RN2117VRN1206V PN0370PN0374 DN1680 FN11174
10.11~10.15 1600 LXV 1TD69 SDN RN2117V PN0374 DN1668DN1680 FN11174
01.12~01.16 1200 LL0 CV48 RN2117V PN0374 DN1680 FN11174
01.05~02.11 1200 LMU 4-Hatchback RN2117V PN0374 DN1680 FN11174
02.16~ 1500 B15D2 T250 RN2117V PN0374 DN1680 FN11174
01.08~01.12 1600 F16D4 TJ6D RN1206VRN2117V PN0370PN0374 DN1680 FN11174

Exemption from liability: the catalog data is advisory and can be used for reference only
