DRUM BRAKE » DN1581H

DN1581H

Specification

Outter Ø
247
Num. of holes
4
Hole Ø
M12x1.25
Centering Diameter
49.4-55.8
Height
71.4
Pitch Circle Ø
108
Drum Ø
203
Structure Material
G3000
Notes
w/Wheel Bearing, w/ABS Sensor Ring

Variation

DN1581[NiBK]

Cross Reference

CITROEN
ZQ51010880
PEUGEOT
4247 47
Peugeot / Citroen
4247 41
Peugeot / Citroen
4247 45
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

PEUGEOT   »   206

03.03~09.09 1400 DV4TD 5DR HB LHD RN1372V PN0201 DN1581 FN0834
10.03~02.08 1400 ET3J4 5DR HB RN1152V PN0364 DN1581RN1396 FN0834PN0270
05.98~09.09 1400 TU3JP 5DR HB RN1961RN1372V PN0201 DN1581DN1560DN1559 FN0557FN0834
04.99~09.09 2000 DW10# Hatchback RN1152VRN1004V PN0364PN0152PN0229 DN1581 FN0602

PEUGEOT   »   206+

02.09~05.13 1400 DV4C 2M 5DR HB RN1372VRN1961 PN0201 DN1581DN1559DN1560 FN0557FN0602FN0834

PEUGEOT   »   207 Compact

12.07~12.12 1400 TU3JP 4-Saloon RN1961 PN0201 DN1581 FN0834
