DRUM BRAKE » DN1570

Specification

Outter Ø
230
Num. of holes
4
Centering Diameter
60.1
Height
56.8
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000
Hole Ø
12.5

Cross Reference

CHEVROLET (GM)
42783310
GM
42783310
GM
95245601
OPEL
05 68 007
OPEL
95245601
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
06.17~ 1000 L5Q 1D#48 DN1570 FN11174
11.15~01.18 1400 LV7 1D#48 PN0689 DN1570 FN11174
09.18~ 1400 LV7 1D#48 US RN2476V PN0689 DN1570 FN11174
01.16~01.22 1400 LV7 DW48 PN0689 DN1570 FN11174
05.15~ 1000 B10XE DN1570 FN11174
05.15~ 1000 B10XL RN2476V DN1570 FN11174

Exemption from liability: the catalog data is advisory and can be used for reference only
