NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2835V

ROTOR DISC » RN2835V

Specification

Type

Vented

Outter Ø

236

Num. of holes

4

Hole Ø:

12.7

Disc Thickness (Max)

20

Disc Thickness (Min)

18

Height

41

Centering Diameter

60.1

Pitch Circle Ø

100

Drum Ø:

125

Front/Rear

Front

Structure Material

G3000

Cross Reference

GM

13584676

GM

5 69 130

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

CHEVROLET (GM) » Spark

09.18~	1400	LV7	1D#48 ASIA LHD	RN2835V	PN34005	DN1570	FN11174
09.18~	1400	LV7	1D#48 LATIN LHD	RN2835V	PN34005	DN1570	FN11174

OPEL » Karl

05.15~03.18

1000

B10XE

RN2835V

PN34005

DN1570

FN11174
