DRUM BRAKE » DN1475

Specification

Outter Ø
259
Num. of holes
5
Hole Ø
13.6
Centering Diameter
113
Height
120
Pitch Circle Ø
150
Drum Ø
220
Structure Material
G3000

Cross Reference

HYUNDAI
52761-44101
HYUNDAI
52761-44102
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.96~12.03 2500 D4BF PA96 LHD RN1095V PN0112 DN1475 FN3350
04.96~12.12 2500 D4BA HA (RUS) RN1095V PN0112 DN1475 FN3350
07.94~04.04 2500 D4BA HFC#  VTN RN1095V PN0112 DN1475 FN3350

Exemption from liability: the catalog data is advisory and can be used for reference only
