ROTOR DISC » RN1095V

RN1095V

Specification

Type
Vented
Disc Thickness (Max)
20
Num. of holes
5
Height
28.7
Centering Diameter
84
Front/Rear
Front
Pitch Circle Ø
106
Outter Ø
253
Drum Ø:
136
Disc Thickness (Min)
18.6
Structure Material
G3000

Cross Reference

HYUNDAI
58129-44010
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HYUNDAI   »   Grace

07.93~10.01 2500 D4BF / 4D56T WGN LONG 12 RN1095V PN0112 FN1879

HYUNDAI   »   H100

03.93~09.03 2400 G4CS FD RN1095V PN0112 DN1515DN1458DN1480 FN1879FN0595
07.93~03.00 2500 4D56/T2 WGN LONG 12 RN1095V PN0112 DN1515 FN1879
07.93~09.03 2500 4D56/T2 WGN LONG 15 LHD RN1095V PN0112 DN1458 FN1879
07.93~10.01 2500 D4BA / 4D56 KMF RN1095V PN0112 DN1515

HYUNDAI   »   H100 Truck

03.96~12.03 2500 D4BF / 4D56T PA96 LHD RN1095V PN0112 DN1475 FN3350

HYUNDAI   »   Porter

04.96~12.12 2500 D4BA / 4D56 HA (RUS) RN1095V PN0112 DN1475 FN3350
07.94~04.04 2500 D4BA / 4D56 HFC#  VTN RN1095V PN0112 DN1475 FN3350
