DRUM BRAKE » DN1432

DN1432

Specification

Outter Ø
300
Num. of holes
5
Hole Ø
14.7
Centering Diameter
107
Height
66
Pitch Circle Ø
139.7
Drum Ø
254
Structure Material
G3000

Cross Reference

DAIHATSU
42431-87602-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

DAIHATSU   »   Feroza

01.89~12.98 1600 HD-# F310 RN1343V PN1291 DN1432 FN0022
01.89~12.98 1600 HD-E F300 RN1343V PN1291 DN1432 FN0022

DAIHATSU   »   Rocky

07.90~05.97 1600 HD-E F300S RN2082 PN1291 DN1432 FN0022
