DRUM BRAKE » DN1340
Specification
Outter Ø
243
Num. of holes
4
Hole Ø
12.5
Centering Diameter
64
Height
60.1
Pitch Circle Ø
100
Drum Ø
203
Structure Material
G3000
Cross Reference
Chery
S21-3502030
MITSUBISHI
MR334866
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.04~09.05 | 1300 | 4A90 | Z21A | RN2034V | PN3500 | DN1340DN1356 | FN1267FN6729 | |
| 10.02~06.12 | 1300 | 4A90 | Z22A | PN3500 | DN1340 | FN6729 | ||
| 10.02~11.04 | 1300 | 4G19 | Z25A | RN2034V | PN3500 | DN1340 | FN6729 | |
| 10.02~10.04 | 1300 | 4G19 | Z26A | RN2034V | PN3500 | DN1340 | FN6729 | |
| 10.04~09.05 | 1500 | 4A91 | Z23A | RN2034V | PN3500 | DN1340DN1356 | FN6729FN1267 | |
| 10.02~06.12 | 1500 | 4A91 | Z24A | RN2034V | PN3500 | DN1340 | FN6729 | |
| 10.02~10.04 | 1500 | 4G15 | Z28A | PN3500 | DN1340 | FN6729 | ||
| 01.03~10.11 | 1500 | 4G15T | Z27A | RN2034V | PN3500 | DN1340 | FN6729 | |
| 06.03~09.11 | 1500 | 4G15T | Z27A | RN2034VRN1944V | PN3462PN3126PN3500 | DN1340RN1923 | FN6729PN3593PN3314 |
| 05.10~06.12 | 1300 | 4A90 | Z22W | RN2034V | PN3500 | DN1340 | FN6729 | |
| 10.04~09.05 | 1500 | 4A91 | Z23W | RN1944VRN2034V | PN3462PN3500 | DN1340DN1356RN1923 | FN1267PN3314FN6729 | |
| 10.04~07.12 | 1500 | 4A91 | Z24W | RN2034V | PN3500 | DN1340 | FN6729 |
| 09.00~08.13 | 1300 | 4G13 | CS1A | RN1222V | PN3462 | DN1340 | FN6729 | |
| 01.03~11.10 | 1500 | 4G15 | CS2A | RN1222V | PN3462 | DN1340 | FN6729FN6723 | |
| 12.04~07.07 | 1500 | 4G15 | CS2W | RN1222V | PN3462 | DN1340 | FN6729 | |
| 09.00~09.13 | 1600 | 4G18 | CS3A | RN1237VRN1222VRN1011V | PN3462PN3469 | DN1341RN1158DN1340 | PN3502FN6729 | FN6704 |
| 09.00~09.13 | 1600 | 4G18 | CS3A GLX LHD | RN1222V | PN3462 | DN1341DN1340 | FN6729 | |
| 06.00~06.07 | 1800 | 4G93 | CS5AR | RN1222V | PN3462 | DN1340 | FN6729 | |
| 12.02~09.09 | 1800 | 4G93 | CS5AZ | RN1222V | PN3462 | DN1340 | FN6729 | |
| 01.00~12.07 | 1800 | 4G93# | CS5A RHD | RN1365V | PN3469 | RN1242DN1340 | PN3502FN6729 | FN6704 |
| 12.04~08.07 | 2000 | 4G94 | CS6A | RN1222VRN1011V | PN3462 | DN1341DN1340 | FN6729 |
| 01.99~02.14 | 660 | 3G83 | U61T | PN3437 | DN1340 | FN6729 | ||
| 01.99~02.14 | 660 | 3G83 | U61TP | PN3437 | DN1340 | FN6729 | ||
| 11.98~12.13 | 660 | 3G83 | U61V | RN1987 | PN3437 | DN1340 | FN6729 | |
| 11.98~12.13 | 660 | 3G83 | U62T | RN1987RN2036 | PN3437 | DN1340 | FN6729 | |
| 11.98~12.13 | 660 | 3G83 | U62TP | RN1987RN2036 | PN3437 | DN1340 | FN6729 | |
| 11.98~02.14 | 660 | 3G83# | U62V | RN1987RN2036 | PN3437 | DN1340 | FN6729 |
