DRUM BRAKE » DN1305

Specification

Outter Ø
256
Num. of holes
4
Centering Diameter
52.3-55
Height
75
Pitch Circle Ø
100
Drum Ø
203.2
Structure Material
G3000

Cross Reference

NISSAN
43206-1HL0A
NISSAN
43206-1HL0B
NISSAN
43206-1HL0C
NISSAN
43206-1HL0E
NISSAN
43206-3HA0A
NISSAN
43206-3HA0B
NISSAN
43206-3HA0C
NISSAN
D3206-1HL0J-NW
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.15~10.16 1200 HR12DE N17P RN22003V PN0397 DN1305 FN1289
09.11~04.19 1200 HR12DE N17T GR RN22003V PN0397 DN1305 FN1289
09.11~04.19 1500 HR15DE N17T GR RN22003V PN0397 DN1305 FN1289
02.10~ 1200 HR12DE BUK13 RHD RN22003VRN1887V PN0397 DN1328DN1305 FN1289FN1280FN1264
09.13~ 1500 HR15DE K13T RN22003V PN0397 DN1305 FN1289
02.11~ 1600 HR16DE K13X RN22003V PN0397 DN1305 FN1289
07.10~10.15 1200 HR12DE K13K RN22003VRN1887V PN0397PN9805 DN1288DN1305 FN0619FN1289
09.10~ 1500 HR15DE K13T RN22003V PN0397 DN1305 FN1289
09.12~07.13 1200 HR12DDR E12 RN22003V PN0397 DN1305 FN1289
09.12~07.13 1200 HR12DE E12 JPN RN22003V PN0397 DN1305 FN1289
04.13~ 1600 HR16DE E12X RN22003V PN0397 DN1305 FN1289
06.11~03.14 1600 HR16DE N17X GL PN0397 DN1305 FN1289
06.11~03.14 1600 HR16DE N17X US RN22003V PN0397 DN1305 FN1289
03.14~07.19 1600 HR16DE N17X US RN22003V PN0397 DN1305 FN1289

Exemption from liability: the catalog data is advisory and can be used for reference only
