DRUM BRAKE » DN1303

Specification

Outter Ø
257.6
Num. of holes
6
Centering Diameter
140
Height
115
Pitch Circle Ø
170
Drum Ø
220
Structure Material
G3000

Cross Reference

NISSAN
43206-10W00
NISSAN
43206-DA00C
NISSAN
43206-T6201
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
06.99~06.07 2000 KA20DE H4F23 RN1893V PN2204 DN1303 FN1163
06.95~06.99 2500 TD25 N4F23 RN1088V PN2344 DN1303 FN1163
01.92~08.97 2700 TD27 P_F23 RN1893VRN1333VRN1088V PN2105PN2204PN2344 DN1303DN1296 FN1174FN1163FN1179
07.92~12.95 2500 TD25 F23 RN1893V PN2204 DN1303 FN1163
07.92~01.03 2700 TD27 F23 RN1088V PN2204FN1159 DN1303 FN1163
10.97~01.11 3200 QD32 F23 RN1088VRN1893V PN2344PN2204 DN1303 FN1163

Exemption from liability: the catalog data is advisory and can be used for reference only
