DRUM BRAKE » DN1259

DN1259

Specification

Outter Ø
271.6
Num. of holes
5
Hole Ø
14.6
Centering Diameter
54.2
Height
71.1
Pitch Circle Ø
100
Drum Ø
228.6
Structure Material
G3000

Cross Reference

TOYOTA
42431-32030
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Camry

08.86~08.90 2000 2C-T CV20 PN1077 DN1258DN1259 FN2232FN2285
08.86~08.98 2000 3S-FE SV21L PN1281 DN1258RN1232DN1259 FN2232FN2285PN1321 FN0633
