DRUM BRAKE » DN1258

DN1258

Specification

Outter Ø
235
Num. of holes
5
Hole Ø
14.6
Centering Diameter
54
Height
65.5
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000

Cross Reference

TOYOTA
42431-32020
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Camry

08.88~07.90 1800 4S-Fi SV22 PN1077 DN1258 FN2285
08.86~08.90 2000 2C-T CV20 PN1077 DN1258DN1259 FN2232FN2285
08.86~08.98 2000 3S-FE SV21L PN1281 DN1258RN1232DN1259 FN2232FN2285PN1321 FN0633

TOYOTA   »   Carina ED

08.90~09.93 1800 4S-FE ST180 PN1077PN1281 DN1258DN1248 FN2285
08.90~09.93 1800 4S-FE ST181 PN1077PN1281 DN1258DN1248 FN2285

TOYOTA   »   Carina II

01.88~12.92 1600 4A-_E AT171 PN1077 DN1258DN1248 FN2285

TOYOTA   »   Celica

10.89~12.93 1600 4A-FE AT180L RN1459V PN1077PN1281 DN1248DN1258 FN2285
08.85~05.98 2000 3S-FE ST162 RN1459VRN1010V PN1281PN1077 RN1232DN1258 PN1321FN2285
10.87~08.89 2000 3S-FE ST162C RN1010V PN1077 DN1258 FN2285
09.89~09.93 2200 5S-FE ST184L RN1459V PN1281 RN1232DN1258 PN1321FN2285 FN0633
09.89~09.93 2200 5S-FE ST184R RN1459V PN1281 DN1258RN1232 PN1321FN2285 FN0633

TOYOTA   »   Corona

12.87~12.92 2000 3S-FE ST171 PN1281 DN1258 FN2285PN1321
01.88~12.92 2000 3S-FE ST171L RN1006V PN1077 DN1258 FN2285

TOYOTA   »   Corona Exiv

08.90~09.93 1800 4S-FE ST180 PN1077PN1281 DN1258DN1248 FN2285
08.90~09.93 1800 4S-FE ST181 PN1077PN1281 DN1258DN1248 FN2285
