DRUM BRAKE » DN1235

Specification

Outter Ø
306
Num. of holes
5
Hole Ø
14.5
Centering Diameter
62
Height
73.3
Pitch Circle Ø
120
Drum Ø
254
Structure Material
G3000

Cross Reference

TOYOTA
42431-04050
TOYOTA
42431-04051
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.04~08.14 2700 2TR-FE TRN220L RN2483V PN1480 DN1235 FN2378
09.04~08.15 2700 2TR-FE TRN225 RN2483V PN1480 DN1235 FN2378
09.04~08.15 4000 1GRFE GRN225 RN2483V PN1480 DN1235 FN2378

Exemption from liability: the catalog data is advisory and can be used for reference only
