ROTOR DISC » RN1533V

RN1533V

Specification

Type
Vented
Disc Thickness (Max)
25
Num. of holes
4
Height
42
Centering Diameter
74
Front/Rear
Front
Pitch Circle Ø
100
Outter Ø
255
Drum Ø:
152
Structure Material
G3000
Disc Thickness (Min)
23

Cross Reference

TOYOTA
43512-0B030
TOYOTA
43512-28130
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Lite/Townace

11.82~10.96 2000 2C CR21G RN1533VRN1342VRN1336VRN1345V PN1404PN1328 FN2232FN2220FN2252
08.85~08.98 2000 2C-T CR21G RN1533VRN1342VRN1336VRN1345V PN1328PN1404 DN1243 FN2232FN2220
08.87~09.93 2000 2C-T CR28G RN1345VRN1533VRN1336V PN1404PN1328 DN1243 FN2220FN2232
09.93~10.96 2200 3C-T CR22G RN1533V PN1328PN1404 DN1243DN1255 FN2232FN2252
09.93~10.96 2200 3C-T CR29G RN1533V PN1328PN1404 DN1243 FN2252FN2232

TOYOTA   »   Liteace

01.92~10.96 2000 3Y-EU YR21G RN1533V PN1328PN1404 DN1243 FN2232

TOYOTA   »   Liteace Noah

10.96~11.01 2000 3S-FE SR40G RN1533VRN1534V PN1404 DN1243 FN2339
10.96~11.01 2200 3C-TE CR40G RN1533V PN1404 DN1243 FN2339

TOYOTA   »   Liteace Van

01.92~10.96 2000 3Y YR39RV RN1533V PN1328 DN1255 FN2252

TOYOTA   »   Qualis

01.00~12.04 2000 RZF50 RN1533V PN1404
01.99~01.05 2400 2L LF50 RN1533V PN1404 DN1255

TOYOTA   »   T.U.V.

04.98~12.04 1800 7K-E KF80R RN1533V PN1404 DN1243 FN2232
