ROTOR DISC » RN2145V

Specification

Type
Vented
Outter Ø
290
Num. of holes
5
Disc Thickness (Max)
24
Disc Thickness (Min)
22
Height
43.8
Centering Diameter
64.2
Pitch Circle Ø
100
Drum Ø:
146
Front/Rear
Front
Structure Material
G3000

Cross Reference

MG
10067751
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.12~ 1500 15S4U RN2145V PN0899PN0785 RN2147 PN0019W

Exemption from liability: the catalog data is advisory and can be used for reference only
