ROTOR DISC » RN2146

Specification

Type
Solid
Outter Ø
260
Num. of holes
4
Disc Thickness (Max)
11
Disc Thickness (Min)
9.6
Height
45.6
Centering Diameter
66
Pitch Circle Ø
100
Drum Ø:
126.8
Front/Rear
Rear
Structure Material
G3000

Cross Reference

LADA
8450031131
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
11.19~ 1600 H4M 2180 RN2142V PN2800 RN2146 PN0197
09.15~ 1600 VAZ-21129 218_ RN2142V PN9805PN2452 DN1627HRN2146 FN0743PN0197
09.15~ 1600 VAZ-21129 2181 RN2142V PN9805 DN1627HRN2146 PN0197FN0743
09.17~ 1600 VAZ-21129 2181 RN2142V PN9805 DN1627HRN2146 PN0197FN0743
09.17~ 1600 VAZ-21129 2181 RN2142V PN9805 RN2146DN1627H PN0197FN0743
09.18~ 1800 VAZ-21179 2181 RN2142V PN2800 RN2146 PN0197

Exemption from liability: the catalog data is advisory and can be used for reference only
